Features
Protect
Can provide overcharge, overdischarge, overcurrent, overtemperature, undertemperature, Protection functions such as short circuit and cell voltage balancing
01
Acquisition accuracy
± 20mV voltage sampling accuracy, ±2% temperature accuracy
02
Charging protection
20A charging current limitation
03
Product Parameters
BPU-D40-16-003 | BPU-D30-16-013 | |
Working voltage | 0-60V | 36-60V |
Charging voltage | 54-60V | |
Continuous charging current | 50A | 50-55A |
Continuous discharging current | 100A | 50-55A |
Working temperature | -30~85℃ | -20~70℃ |
Storage temperature | -40~125℃ | -40~85℃ |
Humidity | 95% | 85% |
